This guide will show you how to run an Internet speed test from the Linux command-line interface (CLI) and cron. You will also see a sample Jenkinsfile if you want to use a Jenkins for the automation instead of cron.
Table of Contents
Speed test command-line options
Several services offer a speed test service via the CLI. Arguably, the most notable of these are speedtest.net by Ookla. You could also use fast.com by Netflix. This guide will show you how to use the speed test CLI service provided by Ookla. So visit https://github.com/sindresorhus/fast-cli for details on using the CLI for Fast.
Speed test CLI from Ookla
Many people trust Ookla’s Speedtest CLI with its global server network. As a result, the command-line tools are well suited for DevOps.
The Speedtest CLI allows you to do the following:
- Measure your Internet connection’s download, upload, latency, and packet loss.
- Do a speed test without relying on a web browser.
- Install the Speedtest CLI on macOS, Debian/Ubuntu, Fedora/Centos/Redhat, and FreeBSD.
- Set up automated scripts to collect connection performance data.
- View test results via CSV, JSONL, or JSON.
Install Speedtest CLI
The following install instructions is a summary from speedtest.net:
macOS
Use the following commands to install Speedtest CLI on macOS:
brew tap teamookla/speedtest
brew update
brew install speedtest --forceDebian/Ubuntu
You can use the following commands to install Speedtest CLI on Debian/Ubuntu:
curl -s https://install.speedtest.net/app/cli/install.deb.sh | sudo bash
sudo apt-get install speedtestFedora/Centos/Redhat
You can use the following commands to install Speedtest CLI on Fedora/Centos/Redhat:
curl -s https://install.speedtest.net/app/cli/install.rpm.sh | sudo bash
sudo yum install speedtestFreeBSD
You can use use the following commands to install Speedtest CLI on FreeBSD:
sudo pkg update && sudo pkg install -g libidn2 ca_root_nss
sudo pkg add "https://install.speedtest.net/app/cli/ookla-speedtest-1.0.0-freebsd.pkg"Run the speed test using the CLI
The following command will run the speed test:
speedtest-cliResult:
Retrieving speedtest.net configuration...
Testing from Starlink (103.150.126.32)...
Retrieving speedtest.net server list...
Selecting best server based on ping...
Hosted by Over the Wire (Sydney) [1.32 km]: 39.851 ms
Testing download speed................................................................................
Download: 57.32 Mbit/s
Testing upload speed......................................................................................................
Upload: 13.59 Mbit/s
The following command will run the speed test and produce JSON output:
speedtest-cli --jsonResult:
{"download": 45898976.19254001, "upload": 17945425.352851078, "ping": 53.928, "server": {"url": "http://speedtest.mirror.digitalpacific.com.au:8080/speedtest/upload.php", "lat": "-33.8600", "lon": "151.2111", "name": "Sydney", "country": "Australia", "cc": "AU", "sponsor": "Digital Pacific", "id": "5744", "host": "speedtest.mirror.digitalpacific.com.au:8080", "d": 1.3224649556794528, "latency": 53.928}, "timestamp": "2021-10-23T20:22:26.022297Z", "bytes_sent": 24059904, "bytes_received": 57511476, "share": null, "client": {"ip": "103.150.126.32", "lat": "-35.8672", "lon": "161.1997", "isp": "Starlink", "isprating": "3.7", "rating": "0", "ispdlavg": "0", "ispulavg": "0", "loggedin": "0", "country": "AU"}}Choose a speed test server
You can choose a specific speed test server using the following command:
speedtest-cli --listResult:
Retrieving speedtest.net configuration...
2173) Internode (Sydney, Australia) [1.32 km]
...Consequently, you can then specify your preferred server using the following command:
speedtest-cli --server 2173Does speedtest-cli not execute when scheduled using cron?
There are a few reasons why the speedtest-cli command may fail when running it via cron:
- First, make sure the path to speedtest-cli is set. Thus call: /usr/bin/speedtest-cli instead of just speedtest-cli.
- Next, make sure you set “#!/bin/bash” in your bash script.
How to execute the speedtest-cli via Jenkins
The following script runs the speedtest-cli via a Jenkins pipeline and then uploads the JSON file to AWS S3.
pipeline {
agent any
stages {
stage('Run test') {
steps {
echo "Send speedtest data to: ${WORKSPACE}/${currentBuild.startTimeInMillis}.json"
echo "Create the script file"
script {
def data = "#!/bin/bash\n/usr/bin/speedtest-cli --json > ${WORKSPACE}/${currentBuild.startTimeInMillis}.json"
writeFile(file: 'test.sh', text: data)
}
echo "Set the execute permissions"
sh "chmod +x test.sh"
echo "Run the test script"
sh "./test.sh"
}
}
stage('Upload to S3') {
steps {
echo "Upload ${currentBuild.startTimeInMillis}.json s3://speedtest-results-starlink/ to S3"
sh "aws s3 cp ${currentBuild.startTimeInMillis}.json s3://speedtest-results-starlink/"
}
}
}
post {
always {
echo 'Cleaup'
sh "rm ${WORKSPACE}/*.json"
}
}
}Wrapping up
You can now run an Internet speed test from the Linux command-line interface (CLI), cron, and Jenkins.
